Overview

OCaml is “an industrial-strength functional programming language with an emphasis on expressiveness and safety.” It was released in 1996 which is the same year that Java was released.

OCaml uses a variant of the Hindley–Milner type system, which is a type inference algorithm for statically typed functional programming languages. The Hindley–Milner type system has the ability to infer the most general types of expressions without requiring explicit type annotations in nearly all cases.

The Caml programming language, released in 1985, is the predecessor of OCaml. The name is short for “Categorical Abstract Machine Language”. OCaml is short for “Objective Caml”. It adds support for object-oriented programming and a more expressive type system.

OCaml is a member of the ML (short for Meta Language) family of programming languages. Other languages that were influenced by ML include Standard ML, Clojure, Elm, Erlang, F#, Haskell, Rust, and Scala. F# was heavily inspired by OCaml and runs on the .NET platform.

F# is to C# as Scala and Clojure are to Java. They are ML-inspired languages that interoperate with an underlying non-ML language.

OCaml has an interpreter, a compiler that compiles to bytecode, and a compiler that creates native executables. OCaml can also be compiled to assembly, C, JavaScript, and WebAssembly.

The OCaml compilers are implemented in OCaml. They are fast compared to the compilers for Haskell and Rust.

OCaml source files have the extension .ml which stands for “meta language”.

The performance of OCaml is generally about 50% that of C.

OCaml supports Foreign Function Interface (FFI) mechanisms to call C functions.

Functional programming languages like OCaml are well-suited for implementing interpreters and compilers. The initial version of the Rust compiler was implemented in OCaml until Rust was mature enough to host itself.

The biggest impediment to OCaml adoption is likely the poor state of library documentation and lack of example code. There is an attempt being made to address this by adding cookbook-like material to the “Learn” section of the main web site.

Notable Features

OCaml has a number of notable features including:

• strong static type checking
• incredible type inference (almost never need to specify types)
• very terse syntax for defining and calling functions
• pattern matching with many ways to match
• automatic function currying
• functional programming (not as pure as Haskell, but more pragmatic)
• object-oriented programming (though not often used)
• variant types (like enums with associated values)
• polymorphic types (OCaml’s version of generics)
• interesting implementation of modules
• pragmatic approach to mutability (immutable by default, but can opt-in to some mutability)
• automatic garbage collection
• fast compared to other non-systems programming languages
• interoperable with C
• package management with OPAM
• comes with an interpreter and two compilers (one to produce bytecode and one to produce native executables)
• Dune build system
• utop REPL

OCaml 5

OCaml version 5 was released in December 2022. It added domains which map to operating system threads.

It also added “effect handlers” which used to be called “algebraic effects”. These are like a try/catch that can resume execution where the effect occurred.

Resources

• OCaml home page

  Click the “Playground” link to experiment with writing OCaml code online.

• My First Experience With OCaml

• OCamlverse Ecosystem

• Learn X in Y minutes Where X=OCaml

• OCaml Programming: Correct + Efficient + Beautiful book used in Cornell CS 3110 course

• OCaml Programming course YouTube videos from Dr. Michael Ryan Clarkson at Cornell University

• Real World OCaml book

• OCaml from the Very Beginning book

• The Caml Humps collection of links to Caml-related tools, libraries, code samples, and tips

• OCaml Wikipedia page

• Introductory Data Structures and Algorithms course from Yale-NUS College

Usage

Ahrefs uses OCaml in its backend systems and data processing pipelines for Search Engine Optimization (SEO) tools and data analysis.

Bloomberg created BuckleScript which compiles OCaml code to JavaScript. In 2022, BuckleScript was renamed to ReScript.

Citrix uses OCaml in the Hypervisor software.

Coq is an interactive theorem prover implemented in OCaml.

Docker uses OCaml in their desktop software for Windows and macOS.

Facebook uses OCaml for many things including:

• Hack programming language (extends PHP with static types)
• Facebook Messenger (the web version)
• Flow static type system for JavaScript
• Infer static analyzer for Java, C, C++, and Objective-C

Haxe is a high-level cross-platform programming language that can be compiled to run on many platforms. Its compiler is implemented in OCaml.

Jane Street uses OCaml for all their financial software, including algorithmic trading. They are one of the largest users and supporters of OCaml.

LexiFi uses OCaml in their financial software for derivatives pricing and risk management.

T3 uses OCaml for algorithmic trading, quantitative analysis, risk management, and other financial software.

Tarides uses OCaml and contributes to the OCaml compiler, platform, and ecosystem.

Derived Languages

Reason (previously called ReasonML) is a syntax extension and toolchain for OCaml developed by Facebook. It provides a more JavaScript-like syntax while retaining full compatibility with the OCaml language and its libraries. The syntax of Reason is more familiar to JavaScript developers than OCaml. It also supports JSX.

ReScript (previously called BuckleScript) is “a robustly typed language that compiles to efficient and human-readable JavaScript”. It was forked from Reason and is not compatible with OCaml.

Melange is a set of tools that work with OCaml and Reason code to generate and interoperate with JavaScript. It supports JSX and can be used to generate React components.

Coq is a formal proof system that is primarily implemented in OCaml.

Installing

To install the OCaml package manager “opam” for Linux and macOS, enter the following shell command which completes in a few seconds:

bash -c "sh <(curl -fsSL https://raw.githubusercontent.com/ocaml/opam/master/shell/install.sh)"

To install for windows, see Install OCaml on Windows.

After installing opam, enter opam init which takes over five minutes to complete.

To install tools for development, enter the following command which takes about four minutes to complete:

opam install ocaml-lsp-server odoc ocamlformat utop

Each of these tools have a dependency on dune, so that is also installed.

To begin using the tools in your current shell, enter eval $(opam env).

Toolchain

The OCaml toolchain consists of the following components that provide everything needed to write, compile, test, debug, and profile OCaml programs and libraries.

• The ocaml interpreter interactive toplevel executes code interactively for testing small code snippets and exploring language features.
• The ocamlc compiler compiles source code into bytecode that can run on any platform. It creates files with the extensions .cmo and .cmi (for interfaces). The -o flag typical typically specifies an output file with a .byte extension that is passed to the ocamlrun command. The .cmo and .cmi files are not needed to run the .byte file, but incremental recompilation relies on them.
• The ocamlrun command executes a bytecode file.
• The ocamlopt compiler compiles source code into an optimized, platform-specific executable.
• The opam package Manager installs libraries and tools, manages dependency versions, and upgrades them.
• The ocamlbuild (predecessor to dune) and dune (modern) build systems simplify building complex and managing dependencies.
• The ocamldoc tool generates documentation from OCaml source code annotations. This is in maintenance mode. Using odoc through Dune is preferred.
• The ocamldebug debugger is used to debug OCaml programs.
• The ocamlprof tool profiles OCaml programs to analyze their performance and identify bottlenecks.
• The standard library provides commonly needed functions and data structures. It includes modules for strings, lists, arrays, I/O operations, and more.

Every source file defines a module, which is a collection of named values that can be constants, functions, and types. An open expression brings the names defined in a module into the current scope. Circular dependencies between modules are not allowed.

Suppose we have the file my_module.ml containing the function definition let add a b = a + b. The name of this module is the name of the file with the first letter uppercased.

Suppose the file main.ml contains the following:

open My_module

let () =
  let sum = add 1 2 in
  print_int sum

The syntax () represents the “unit value” and represents not having a value.

Ending a source file that is the starting point of a program with let () = followed by an expression is not required, but it ensures that the result of the expression will be the unit value. It also makes it clear that the purpose of the expression is the side effects it produces.

It is recommended to create a Dune project, move these files into the project bin directory, and run it with dune exec {project-name}. See the Dune section below for more detail.

However, there are several options for building and running a project without using Dune.

To compile this to an executable and run it, enter ocamlopt my_module.ml main.ml -o main and ./main.

To compile this to bytecode and run it, enter ocamlc my_module.ml main.ml -o main.byte and ocamlrun main.byte.

To compile this to an executable and run it by specifying only the main source file, enter ocamlbuild main.native and ./main.native. The ocamlbuild command creates a _build directory containing many intermediate files that are not needed to run the program.

To compile this to bytecode and run it by specifying only the main source file, enter ocamlbuild -cflags -g main.byte and ocamlrun main.byte.

Help

For help on OCaml, see:

• OCaml Discord
• OCaml Discourse
• OCaml style guide

Also use the odig tool. To install it, enter oapm install ocaml-manual odig. To use it, enter odig doc. The first time this is run it will take five minutes or so to update the documentation. After that, running it will open a browser tab. This links to external documentation pages that are typically brief and lacking in examples.

VS Code

Install the “OCaml Platform” extension from OCaml Labs.

Create the file .ocamlformat in each project root directory containing at least the following in order for VS Code to format OCaml code on save.

profile = default
version = 0.26.1

For documenation on ocamlformat options, see Manpage: ocamlformat.

To try the options online, see OCamlFormat configurator.

You may want to add these:

break-infix = fit-or-vertical
if-then-else = fit-or-vertical
parse-docstrings = true
wrap-comments = true

Copy the .ocamlformat into every subdirectory that contains its own dune-project file.

Sometimes after code changes VS Code flags errors that aren’t real. Running “Developer: Reload Window” from the command palette clears them. This issue may go away if you run dune build -w (for watch mode) in a terminal window. Doing this is useful anyway because there may be errors that dune build will flag, but the Language Server Processor (LSP) used in VS Code will not.

Expressions

An expression in OCaml can be a:

• literal value - ex. true, 3, 3.14, or “hello”
• variable - ex. x
• let variable declaration - ex. let x = 3
• let function declaration - ex let double x = x * 2
• keyword expression - ex. if ... or for ...
• function call - ex. double 3
• sequence of any of the above separated by semicolons

When using a sequence of expressions, all but the last must evaluate to the unit value. The ignore function can be applied to any expression to ignore its result. That function takes any value and returns the unit value ().

The following code shows two ways to ignore the return value of a function. Assume the add_dog function returns a dog record.

ignore (add_dog "Comet" "Whippet");
add_dog "Oscar" "German Shorthaired Pointer" |> ignore;
print_endline "finished adding dogs"

REPL

OCaml has two REPLs. A basic one can be started by entering ocaml. A better REPL is utop which is short for “Universal TOPlevel”. The utop command provides a more interactive, user-friendly interface that includes line editing, syntax highlighting, command history, and tab completion.

In either REPL the expressions you enter are only evaluated when they are terminated by a double semicolon (;;). This allows entering a series of expressions that are separated from each other by a single colon and allows them to span multiple lines. For example:

print_int (2 + 3);
print_int (2 * 3);; (* 56 *)

Double semicolons are only used in REPL sessions, not in source files (except when assigning global identifiers).

When an expression is entered, utop will output its name, inferred type, and value. For example, entering let x = 7;; will output val x : int = 7;.

If the expression does not have a name, the part to the left of the colon will be a dash. For example, entering a raw value like 7;; or an anonymous function like fun x -> x * x;; will do this. But entering a named function like let square x = x * x;; will output the name.

Use the left and right arrow keys to move the cursor within the expression and make edits.

Use the up and down arrow keys to recall previously entered expressions. These can be edited and executed again.

To show the type of an expression e, enter #show e;;

To load definitions from an OCaml source file into the REPL, enter #use "{file-path}";;. This enables using all the types and functions defined in the source file inside the REPL.

To configure utop options that should be used every time it is started, create the file ~/.config/utop/init.ml. For example, the following automatically requires and opens the Core module and makes the output less noisy.

#require "Core";;
open Core;;
#utop_prompt_dummy;;

To remove the typeahead hint boxes, add UTop.set_show_box false.

To trace the flow of function execution, enter #trace {fn-name};;. Then enter a call to the function. This is especially useful for recursive functions. To stop tracing the function, enter #untrace {fn-name};;.

To exit the REPL, press ctrl-d or enter #quit.

There is also an iOS app called “OCaml” for evaluating OCaml expressions.

Comments

Comments in OCaml code begin with (* and end with *). They can span any number of lines and can be nested. There is no syntax for single-line comments.

Doc comments provide documentation that can be extracted from source files. They begin with (** and end with *). Their content is similar to JSDoc comments, including the use of @param and @return annotations. There are three variations of doc comments, floating, item, and label.

Primitive Types

OCaml supports the following primitive types. Their sizes depend on the CPU.

• unit - one literal value ()
• bool - 1 byte with the literal values true and false
• char - 1 byte ASCII, not Unicode
• int - 8 or 4 bytes
• float - 8 bytes
• string - sequence of bytes, not Unicode characters

Unit represents having no value and is the return type of functions that don’t return anything.

The functions succ and pred operate on int and float values and return the value one higher or one lower.

Single literal characters are delimited by single quotes.

Literal strings are delimited by double quotes. The ^ operator is used to concatenate strings.

The Char and String modules provide many functions for operating on values of these types.

Some libraries assume that sequences of bytes in a string represent Unicode characters. See the libraries Uutf, Uutf_string, and ocaml-unicode.

Primitive values are expressions that do not require additional evaluation.

OCaml does not support null values.

There is a corresponding standard library module for each of these whose name begins uppercase. These provide functions for operating on values of the type.

Primitive Type Conversions

The OCaml standard library provides many functions for converting a value from one type to another. Examples include:

• bool_of_string - raises Failure if conversion fails
• bool_of_string_opt - returns None if conversion fails
• char_of_int
• float_of_int
• float_of_string - raises Failure if conversion fails
• float_of_string_opt - returns None if conversion fails
• int_of_char
• int_of_float - truncate is an alias
• int_of_string - raises Failure if conversion fails
• int_of_string_opt - returns None if conversion fails
• string_of_bool
• string_of_float
• string_of_int

There is no string_of_char function. To convert a char expression c to a string value, use String.make 1 c.

Naming Conventions

It is idiomatic in OCaml for

• variable, function, and class names to use snake_case with all lowercase letters
• module names and variant constructors to use CamelCase, starting with an uppercase letter

It is idiomatic in OCaml for the name of a function that

• transforms a value of type x to a value of type y to be y_of_x
• returns a Option value to end in _opt
• raises an exception to end in _exc

Keywords

OCaml reserves the use of the following identifiers: and, as, assert, asr, begin, class, constraint, do, done, downto, else, end, exception, external, false, for, fun, function, functor, if, in, include, inherit, initializer, land, lazy, let, lor, lsl, lsr, lxor, match, method, mod, module, mutable, new, nonrec, object, of, open, or, private, rec, sig, struct, then, to, true, try, type, val, virtual, when, while, and with.

Operators

OCaml operators only operate on specific types. This enables type inference of function return types because the compiler can determine the types required by its code. It is a very important way in which OCaml differs from most other programming languages.

Operators for float values are the same as those for int values, but with a . added to the end.

The arithmetic operators include:

The - and -. operators can also be used for unary negation, but in some cases their meaning is ambiguous. That is why the ~- and ~-. operators are provided.

There is no exponentiation operator for int values in the standard library.

When using the Base module:

• the ** operator performs int exponentiation
• the **. operator performs float exponentiation
• the % operator performs modulo

There are no operators like ++ and -- to increment or decrement a number. Instead use the functions succ and pred to get the successor or predecessor. For refs that hold an int value, use the functions incr and decr.

The string operators include:

The relational and logical operators include:

The = operator is also used with the let keyword for assignment.

The remaining operators include:

The function application and reverse function application operators provide an alternative to surrounding nested function calls with parentheses. The @@ operator cannot follow assert because that is not a normal function.

For example:

let double x = x * 2
let square x = x * x
let () =
  (* All the remaining expression print 16. *)

  let d = double 2 in
  let s = square d in
  print_int s;

  print_int (square (double 2))

  print_int @@ square @@ double @@ 2

  2 |> double |> square |> print_int

Most OCaml operators are implemented as binary functions. To use them as functions, wrap them in parentheses. For example, a + b is the same as (+) a b. Adding spaces inside the parentheses is optional, but is required for the * operator because (* is interpreted as the beginning of a comment.

Operator functions can be passed to functions like List.filter.

The following code demonstrates writing a function that takes a comparison function, which can be a logical operator. The choose function takes two lists and a comparison function. It returns a new list where each element is the element from the first or second list at the same index where comparing them using the comparison function evaluates to true.

let rec choose list1 list2 cmp_fun =
  (* match is described in the "Conditional Logic" section. *)
  match (list1, list2) with
  | [], [] -> [] (* both lists are empty; return empty list *)
  | [], _ -> list2 (* first list is empty; return second list *)
  | _, [] -> list1 (* second list is empty; return first list *)
  | h1 :: t1, h2 :: t2 ->
      if cmp_fun h1 h2 then
        h1 :: choose t1 t2 cmp_fun (* add h1 to result list *)
      else h2 :: choose t1 t2 cmp_fun (* add h2 to result list *)

let l1 = [ 1; 3; 4; 6; 9; 10 ]
let l2 = [ 7; 1; 0; 8; 6; 4 ]

let () =
  List.iter
    (fun x ->
      print_int x;
      print_string " ")
    (choose l1 l2 ( > )) (* relational operator passed here *)

The result is [7; 3; 4; 8; 9; 10].

Custom binary operators can be defined using an allowed set of characters.

The open keyword brings all the identifiers in a given module, printf in this case, into scope so they can be used without prefixing them with their module name.

For example:

open Printf

type point = { x : float; y : float }

(* This operator adds two points. *)
let ( +! ) (p1 : point) (p2 : point) : point =
  { x = p1.x +. p2.x; y = p1.y +. p2.y }

(* This is an alternate way to define the same operator. *)
let ( +! ) { x = x1; y = y1 } { x = x2; y = y2 } =
  { x = x1 +. x2; y = y1 +. y2 }

(* This shadows the built-in + operator to perform subtraction instead,
   but only in the current scope. *)
let ( + ) (n1 : int) (n2 : int) : int = n1 - n2

let () =
  let p1 = { x = 1.; y = 2. } in
  let p2 = { x = 4.; y = 6. } in
  let p3 = p1 +! p2 in
  printf "(%F, %F)\n" p3.x p3.y; (* { x = 5.; y = 8. } *)

  let n1 = 2 and n2 = 3 in
  printf "%d\n" (n1 + n2) (* -1 *)

Variables

Variables are immutable. An exception is that variables in a REPL can be reassigned.

Identifier names must start with a lowercase letter unless they refer to a module, variant constructor, or “polymorphic variant tag”. They can contain letters, digits, and the underscore character. They can also end with single quotes to create names like like x' (for x prime) and x'' (for x double-prime). Technically an identifier can contain any number of single quotes and they can appear anywhere except at the beginning, but doing this is odd.

A let expression binds an identifier to the value of an expression whose scope is the expression that follows the in keyword. The value of a let expression is the value of its expression with all occurrences of the identifier replaced with its value. For example, here are three ways to write a let expression that evaluates to 3:

let a = 1 in
let b = 2 in
a + b

let a = 1 and b = 2 in
a + b

let a, b = 1, 2 in
a + b

Note how the expression that follows a let expression can be another let expression in order to place multiple identifiers into the scope of the final expression.

It is a common error to write let variable = expression; instead of let variable = expression in. When this is done, your editor should flag it with the message “Warning 10: this expression should have type unit”. If you compile the code, the message “Error: Syntax error” will be output and will refer to the last line in the file, which is unhelpful.

Identifiers bound by let expressions go out-of-scope after they are evaluated.

The type of a variable can be specified, but typically this is omitted because the type can be inferred.

let a : int = 1 in
let b : int = 2 in
a + b

While it is not required to include a space on both sides of the colon when specifying a type, it is customary and the ocamlformat code formatter will add them.

A let definition omits the in keyword. These are used inside modules to create global definitions that do not go out of scope after they are evaluated. They are not expressions, so they do not have a value.

The following example from a REPL session binds three global identifiers. Note how a double semicolon is used to terminate the assignments of global identifiers.

In order to call a function that takes no arguments, such as print_newline, it must be passed the unit value (). Without this it is just a reference to the function and not a call to it.

let a = 1
let b = 2
let c = 3;;

print_int (a + b);
print_newline ();
print_int (b + c);
print_newline ()

A let expression can use pattern matching to bind any number of variables to elements in various collection types. This is similar to JavaScript destructuring.

The syntax let pattern = expression in ... is the same as writing match expression with pattern -> ..., but match supports multiple patterns. Types like lists and arrays always need more than one path to avoid getting a warning for a non-exhaustive match. For example:

open Printf

let my_tuple = (1, 2, 3)
let my_list = [ 1; 2; 3 ]
let my_array = [| 1; 2; 3 |]

type my_record_type = { first : int; second : int; third : int }

let my_record = { first = 1; second = 2; third = 3 }

let () =
  (* Only one pattern is needed because tuples have a fixed structure.
     The single pattern is "irrefutable". *)
  let a, b, c = my_tuple in
  printf "tuple: a = %d, b = %d, c = %d\n" a b c;

  (* Same for records. *)
  let { first; second; third } = my_record in
  printf "record: first = %d, second = %d, third = %d\n" first second third;

  (* Multiple patterns are needed for types with a variable structure
     like lists, arrays, and variants. *)
  (* We can match on a list that contains at least some number of elements. *)
  (match my_list with
  | a :: b :: c :: _ -> printf "list: a = %d, b = %d, c = %d\n" a b c
  | _ -> print_endline "list doesn't contain at least 3 elements");

  (* We cannot do this for an array.
     Instead we must match on a specific number of elements. *)
  match my_array with
  | [| a; b; c |] -> printf "array: a = %d, b = %d, c = %d\n" a b c
  | _ -> printf "array doesn't contain exactly 3 elements\n"

Type Variables

OCaml supports type variables which are similar to generics in other languages. Type variables serve as a placeholder for an unknown type. They are written with a single quote followed by a lowercase name.

Often the name is just 'a and is pronounced “alpha”. If additional type variables are needed, it is common to use 'b (beta) and 'c (gamma). Other common type variable names are 'k for a key type and 'v for a value type.

For example, entering [];; in utop outputs type type 'a list because it is a list where the type of the elements is unknown.

The following code demonstrates writing a function that uses parametric polymorphism to find the largest value in a list of values.

(* The next 2 lines can be replaced by the following
   omits the type specifications:
   let rec max_element = function *)
let rec max_element (ls : 'a list) : 'a option =
  match ls with
  | [] -> None (* for an empty list *)
  | [ x ] ->
      Some x (* for a list with only one element *)
  | hd :: tl -> (
      match max_element tl with
      | None ->
          Some hd (* head is maximum if tail is empty *)
      | Some max_tl -> Some (if hd > max_tl then hd else max_tl))

(* This is a more compact way to write the function above. *)
let max_element = function
  | [] -> None
  | hd :: tl -> Some (List.fold_left max hd tl)

let () =
  let numbers = [ 1; 13; 4; 9 ] in
  let max = max_element numbers in
  match max with
  | None -> print_endline "empty list"
  | Some max -> print_int max (* 13 *)

References

While variables are immutable, they can be bound to a reference holds a mutable value. References are created with the ref function which must be given an initial value. The initial value determines its type.

The ! prefix operator dereferences a ref to obtain its value. It does not negate a bool value. The not function is used for that.

The := operator assigns a new value to a ref.

For example, the following code sets the variable score to a reference to 0. The while loop increments the value until it reaches 10.

let score = ref 0 in
while !score < 10 do
  score := !score + 1;
  print_int !score;
  print_newline ()
done

For int refs, the incr and decr functions can be used to increment and decrement their value.

Refs are actually single field records with a mutable field named contents. The ref operators are just shorthand for accessing that field. If r is a variable bound to a ref then !r is short for r.contents and r := expr is short for r.contents <- expr.

Other kinds of values in OCaml that support mutation include arrays and record fields (when marked as mutable). Values created with the following standard library modules also support mutation: Atomic, Bytes, Hashtbl, Mutex, Queue, Semaphore, and Stack.

A function can hold a ref in its scope using a closure. For example, the following function returns the next int value every time it is called.

let next =
  let last = ref 0 in
  fun () ->
    incr last;
    !last

Call this repeatedly with next ().

Algebraic Data Types (ADTs)

OCaml supports algebraic data types which include product types and sum types.

Product types (aka “each-of types”) describe a conjunction which can be thought of as “this AND this AND this”. They can hold multiple pieces of data with differing types. Examples of product types in OCaml include tuples and records.

Tuples describe a cartesian product of values. For example, the tuple type float * float describes the combination of every possible float value (say an x-coordinate) with every possible float value (say a y-coordinate).

Sum types (aka “one-of types”) describe alternatives with a disjunction which can be thought of as “this OR this OR this”. Examples of sum types in OCaml include the primitive type int and variant types (described later). Lists and trees are implemented as variant types. The elements in a list are represented as a variant whose value can be the empty list ([]) or a cons cell created with the :: operator that represents a value and a list tail. A tree can be represented as a variant whose value can be Empty or Node where nodes have a value and references to nodes representing left and right subtrees.

Lists are sum types because they can be either an empty list or a head and tail (where the tail can be an empty list). Lists are also product types because they hold a head and a tail which have different types.

Generalized Algebraic Data Types (GADTs)

GADTs are an extension to ADTs that support more precise type specifications (more constraints) and enable better type inference in certain situations.

GADTs are a step toward supporting dependent types. Dependent types enable defining types whose meaning depends on values. For example a list type can specify a fixed length and/or that its values must be in ascending order.

TODO: Add more detail on GADTs.

Type Aliases

The type keyword defines a type alias. It is used to define shorthand name for a type definition (such as a variant type) or to define an alias for an existing type.

For example:

type weight = float
type point = float * float (* a tuple *)

Variant Types

Variant types have many uses including enumerated values, error handling, and representing data structures whose shape can vary.

Each variant name is called a “constructor” (aka “tag”) and must begin with an uppercase letter. Each constructor can have an associated value of a type that is specified after the of keyword. The value types of the variants can differ.

To see all the constructors of a variant type in utop, enter #show {variant-type}.

Constructor expressions that do not use a value are referred to as “constant variant expressions”. The following code provides some examples:

type season = Spring | Summer | Fall | Winter
type tense = Spring | Sprung | Sprang

(* The first vertical bar here is optional.
   When pattern matching a sum type, if all variants aren't matched,
   the warning "this pattern-matching is not exhaustive" will appear.
   Since both the season and tense types define a Spring constructor,
   we need to specify which variant type to use. *)
let forecast : season -> string = function
  | Spring -> "rain"
  | Summer -> "sun"
  | Fall -> "nice"
  | Winter -> "snow"

let get_tense : tense -> int = function
  | Spring -> 1
  | Sprang -> 2
  | Sprung -> 3

let () =
  print_endline (forecast Winter);

Another option to avoid constructor name conflicts is to wrap the conflicting variant type in a struct. It is idiomatic for the main type in a module to be named “t”.

module Tense = struct
  type t = Spring | Sprung | Sprang
end

let tense = function Tense.Spring -> 1 | Tense.Sprang -> 2 | Tense.Sprung -> 3

One more option is to a prefix to the constructor names so they don’t collide.

type season = SSpring | SSummer | SFall | SWinter
type tense = TSpring | TSprung | TSprang

Variants that do use a value are referred to as “non-constant variant expressions”. These are similar to TypeScript type unions. The following code provides some examples:

type my_union = BoolVal of bool | IntVal of int | StringVal of string

let get_string = function
| BoolVal b -> string_of_bool b
| IntVal i -> string_of_int i
| StringVal s -> s

let () =
  let b = BoolVal true in
  let i = IntVal 10 in
  let s = StringVal "hello" in
  print_endline (get_string i);
  print_endline (get_string s);
  print_endline (get_string b)

The following code uses a variant type to describe shapes.

type point = float * float

type shape =
  | Circle of { center : point; radius : float }
  | Rectangle of { lower_left : point; width : float; height : float }

let area = function
  | Circle { radius = r } -> Float.pi *. r *. r
  | Rectangle { width = w; height = h } -> w *. h

let center shape =
  match shape with
  | Circle { center = c } -> c
  | Rectangle { lower_left = x, y; width = w; height = h } ->
      (x +. (w /. 2.), y +. (h /. 2.))

let () =
  let c = Circle { center = (0., 0.); radius = 10. } in
  let r =
    Rectangle { lower_left = (0., 0.); width = 10.; height = 5. }
  in
  printf "c area = %f\n" (area c); (* 314.159265 *)
  printf "r area = %f\n" (area r); (* 50.0 *)
  let x, y = center c in
  printf "c center = (%f, %f)\n" x y; (* (0.0, 0.0) *)
  let x, y = center r in
  printf "r center = (%f, %f)\n" x y; (* (5.0, 2.5) *)

Variant types can be parameterized. For example:

open Printf

(* A tree can be empty or it can have a node
   that holds a left tree, a value, and a right tree. *)
type 'a tree = Empty | Node of 'a * 'a tree * 'a tree

let rec depth_first_in_order tree =
  match tree with
  | Empty -> () (* do nothing *)
  | Node (value, left, right) ->
      depth_first_in_order left;
      print_endline value;
      depth_first_in_order right

(* This holds names in a tree so that when
   printed with depth_first_in_order
   they will appear in sorted order. *)
let family_tree : string tree =
  Node
    ( "Jeremy",
      Node ("Amanda", Empty, Empty),
      Node
        ( "Meghan",
          Node ("Mark", Empty, Empty),
          Node ("RC", Empty, Node ("Tami", Empty, Empty)) ) )

let () = depth_first_in_order family_tree

Option Variant Type

The Option module defines a variant type represents an optional value. It has the constructors None and Some defined by type 'a option = None | Some of 'a.

Functions that sometimes do not have a value to return use this type to represent their return value. For example, the List.find_opt function does this.

open Printf

let colors = [ "red"; "green"; "blue" ]
let color = "green"
let result = List.find_opt (fun x -> x = color) colors

let () =
  match result with
  | Some c -> printf "found %s\n" c
  | None -> print_endline "failed to find green\n"

The Option module defines many functions that operate on an Option value. Many of these have operator equivalents.

Option.value extracts the value from an Option and provides a default value to use when it is None. Option.fold is similar, but it takes a function that is called to produce the return value when it is a Some. The following code demonstrates using both of these.

type dogt = { name : string; breed : string }

let dog1_opt = None
let dog2_opt = Some { name = "Comet"; breed = "whippet" }

let () =
  let dog = Option.value ~default:{ name = "?"; breed = "?" } dog1_opt in
  print_endline dog.breed;

  let breed =
    Option.fold ~none:"unknown"
      ~some:(fun dog -> String.uppercase_ascii dog.breed)
      dog2_opt
  in
  print_endline breed

Option.map applies a function to the value inside an Option and return a new Option. If it is Some v then the result of passing v to the function is returned in a Some variant. If it is None then None is returned. The operator >>| is often defined to use this.

For example:

let double x = x * 2
let is_even x = x mod 2 == 0

let () =
  let numbers = [ 1; 4; 7 ] in
  List.find_opt is_even numbers
  |> Option.map double |> Option.map string_of_int
  |> Option.value ~default:"no even found"
  |> print_endline

Option.bind is used in reverse function application chains so a function that returns an Option can have the value inside it passed to the next function in the chain. If any function returns None, the remaining functions are not called and the value of the entire chain is None. The operator >>= is often defined to use this.

Result Variant Type

The Result module defines a variant type represents the result of a function that can succeed or fail. It has the constructors OK and Error.

For example:

let divide numerator denominator =
  if denominator = 0. then Error "cannot divide by zero"
  else Ok (numerator /. denominator)

let () =
  let n = 5. and d = 0. in
  match divide n d with
  | Ok v -> print_endline (string_of_float v)
  | Error e -> print_endline e

Interpreter

Variant types can be used to build interpreters. For example:

type expr =
  | Int of int
  | Add of expr * expr
  | Sub of expr * expr
  | Mul of expr * expr
  | Div of expr * expr

let rec eval = function
  | Int n -> n
  | Add (e1, e2) -> eval e1 + eval e2
  | Sub (e1, e2) -> eval e1 - eval e2
  | Mul (e1, e2) -> eval e1 * eval e2
  | Div (e1, e2) -> eval e1 / eval e2

let () =
  let result = eval (Add (Int 5, Mul (Int 3, Int 2))) in
  print_endline (string_of_int result)
  (* 5 + (3 * 2) = 11 *)

Conditional Logic

Conditional logic is implemented with the if and match expressions.

if expression

The syntax is if expr1 then expr2 else expr3.

expr1 must evaluate to a bool. Non-bool values are not automatically coerced to a bool value. For example, 0 is not treated as false.

expr3 must evaluate to the same type as expr2 so the if expression always evaluates to the same type.

For example:

let sign = if result > 0 then "positive"
  else if result < 0 then "negative"
  else "zero"

To include multiple expressions after then or else, surround them with parentheses and separate them with semicolons. The value will be the value of the final expression.

As an alternative to parentheses, the begin and end keywords can be used. However, OCaml editor extensions may automatically replace those with parentheses.

Unless the then branch produces a unit result, an else branch is required.

An if expression can be used where other languages use a ternary operator.

match expression

A match expression performs pattern matching. It takes an expression whose value is to be matched and a set of branches. Each branch begins with a vertical bar (|) followed by a pattern, the characters ->, and code to execute when the pattern is matched. The vertical bar before the first branch is optional.

A match expression is somewhat like a switch statement in other programming languages. You can think of the vertical bar at the beginning of each branch as being like the case keyword in those languages.

The type of a match expression is the type of its branch expressions, which must all evaluate to the same type.

The patterns must be exhaustive, meaning that there must be a pattern that matches every possible value. Using the catch-all _ as the final pattern satisfies this.

The patterns can match:

• a constant (ex. | 7 or | "summer")
• a range of characters (ex. | 'a' .. 'f')
• a variant type constructor (ex. | None or | Some x)
• a tuple (ex. | (_, "summer", temperature) which means we don’t care about the first element, the second element must be "summer", and we want to capture the value of the third element)
• a list (ex. | [] or | ["summer"; other] or | first :: second :: rest)
• an array (ex. | [||] or | [|"summer"; other|])
• a record (ex. | {name; age = a})
• multiple match expressions (ex. | 7 | 8 | 9)
• a variable to match anything and bind the value to it
• a guard using the when keyword (ex. | n when 7 <= n && n <= 9)
• the catch-all _ which doesn’t bind the value

The patterns are checked in the order they are specified and the first matching pattern is used, so their order matters.

The value of a match expression is the value after the matched pattern.

There is a warning if the branches are not exhaustive. At runtime if no branch matches, a Match_failure exception is raised.

For example:

let () =
  Random.self_init ();
  let n = Random.int 10 in
  print_endline (string_of_int n);
  match n with
  | 0 | 1 | 2 | 3 -> print_string "small"
  | n when 4 <= n && n <= 7 -> print_string "medium"
  | _ -> print_string "large"

The as keyword is used to bind a name to the entire matched expression. For example:

let my_tuple = (true, 3)

let () =
  match my_tuple with
    | (b, n) as t -> Printf.printf "%b, %d, %b, %d\n" b n (fst t) (snd t)
    | _ -> print_endline "will never happen"

The function keyword defines a function, like the fun keyword, but it’s specialized to perform pattern matching on its first argument. It is useful in functions that immediately match on the last parameter. It simplfies the code by removing the need to list the last parameter and replaces match {last-parameter} with with just function. For example:

type season = Winter | Spring | Summer | Fall

let weather s =
  match s with
  | Winter -> "cold"
  | Spring -> "cool"
  | Summer -> "hot"
  | Fall -> "perfect"

(* same as previous function *)
let weather2 = function
  | Winter -> "cold"
  | Spring -> "cool"
  | Summer -> "hot"
  | Fall -> "perfect"

let () =
  print_endline (weather Fall); (* perfect *)
  print_endline (weather2 Fall); (* perfect *)

The following code uses the function keyword to transform a list of Option values to a list of unwrapped values where a default value is used for None cases.

let options = [ Some 1; None; Some 2 ]
let values = List.map (function Some x -> x | None -> 0) options
let () = List.iter (Printf.printf "%d\n") values
(* outputs 1, 0, and 2 *)

Iteration

The for and while keywords support imperative iteration. It is more typical in OCaml to use recursion for iteration.

A for loop specifies start and stop values, but it cannot specify a step size.

The expression inside a for loop must have a unit value, which means that the loop itself doesn’t return a value.

There are no break or continue statements like in other languages.

The following code demonstrates for loops.

open Printf

let () =
  for i = 1 to 5 do
    printf "%d\n" i
  done;

  for i = 5 downto 1 do
    printf "%d\n" i
  done

A while loop specifies a boolean condition. This might be an expression involving a ref whose value changes or a function that returns a value to be tested. The loop terminates when the condition evaluates to false.

The following code demonstrates while loops.

open Printf

let () =
  let i = ref 1 in
  while !i <= 5 do
    printf "%d\n" !i;
    incr i
  done

To iterate over collections like lists and arrays it’s best to use iter functions instead of for or while loops.

open Printf

let () =
  let numbers = [ 1; 2; 3; 4; 5 ] in
  List.iter (fun x -> printf "%d\n" x) numbers;

  let numbers = [| 1; 2; 3; 4; 5 |] in
  Array.iter (fun x -> printf "%d\n" x) numbers

Collections

OCaml has built-in support for many kinds of collections. The most commonly used are tuples, lists, arrays, and maps.

Each of these collection types are described in more detail below. All but Set, Map and Hashtbl have a literal syntax. Tuples separate elements with commas and all the others use semicolons.

• tuple - (expr1, expr2, ...)
• list - [ expr1; expr2; ... ]
• array - [| expr1; expr2; ... |]
• record - { k1 = expr1; k2 = expr2; ... }

Also see these modules:

• Array
• Hashtbl
• List
• Map
• Queue
• Seq
• Set
• Stack

Tuples

A tuple is an immutable, ordered collection of values whose types can differ.

To create a tuple, surround the elements in parentheses and separate them with commas. For example:

let t = (true, 3, "blue") in
(* Can use pattern matching to extract the values. *)
let (b, n, c) = t in
printf "b = %b, n = %d, c = %s\n" b n c

In practice it is rare for a tuple to contain more than three values. Tuples with two elements are referred to as a “pair” and those with three elements are referred to as a “triple”.

The parentheses shown above for creating and pattern matching on a tuple are optional, but are recommended for clarity.

The variable t above has the type bool * int * string which is referred to as a “product type” (based on tuples being similar to cartesian products).

Fun fact: The Greek word “aster” means “star”, so it makes sense to refer to the asterisk character as “star”.

For pairs, the fst function returns the first element and the snd function returns the second. There are no built-in functions for operating on longer tuples.

Pattern matching can be used to get a specific element from a tuple. The following code shows four ways to write a function that returns the third element of a 4-element tuple.

let third_of_4 t = match t with _, _, c, _ -> c
let third_of_4 = function _, _, c, _ -> c
let third_of_4 t = let _, _, c, _ = t in c
let third_of_4 (_, _, v, _) = v

let t = ("alpha", "beta", "gamma", "delta") in
print_endline (third_of_4 t) (* gamma *)

You can think of tuples like records (described later) where the fields are accessed by position rather than name.

Lists

A list is an immutable, ordered collection of values that all have the same type. Lists are implemented as a variant type with two constructors whose values form a singly linked list. The first constructor is [] (pronounced “nil”), which represents an empty list. The second constructor is :: (pronounced “cons”, short for “construct”) which creates a new list by adding an element to the beginning of an existing list.

To create an empty list, use the nil constructor. For example:

let issues = []

To create a non-empty list, surround the elements in square brackets and separate them with semicolons. For example:

let colors = ["red"; "green"; "blue"]

Using commas instead of semicolons is a common error. When that is done, a list containing a single tuple is created.

A non-empty list is represented by a head that holds an element value and a tail that holds the remainder which is another list that may be empty.

To create a new list by adding an element to the beginning of an existing list, use the cons constructor. The right side must be a list and the left side must be an expression that evaluates to the same type as elements in the list on the right. As an operator, this is right-associative. For example:

let new_list = element :: old_list

The color list above was written with syntactic sugar for the following which is evaluated from right to left to construct the final list:

let colors = "red" :: "green" :: "blue" :: []

To create a new list by concatenating two lists, use the @ operator. For example:

let new_list = list1 @ list2

The type of a list is written as t list where t is the type of the elements. For example, the type of a list of float values is float list. The type of an empty list [] is 'a list where 'a is a type variable that represents an unknown type.

List elements can themselves be lists, but all the elements must then also be lists with the same element type. The sublists are not required to have the same length. For example:

let seasons = [
  ["spring"; "rain"];
  ["summer"; "heat"];
  ["fall"; "nice"];
  ["winter"; "cold"]
]

The type of seasons is string list list.

A match expression can be used to recursively process a list. For example, the following code computes the sum of a list of integers. By convention, the name hd is used for the head of a list and the name tl is used for the tail.

Here are three ways to write a function that takes an int list and returns the sum of the elements.

let rec sum list =
  match list with
  | [] -> 0
  | hd :: tl -> hd + sum tl

let rec sum = function
  | [] -> 0
  | hd :: tl -> hd + sum tl

let rec sum = List.fold_left (+) 0

The standard library provides many functions that operate on lists. See the List module. Some highlights include the following:

Since tuple elements are separated by commas and list elements are separated by semicolons, a list of tuples can be written as follows:

["alpha", 1; "beta", 2; "gamma", 3]

This evaluates to the following list of tuples:

[("alpha", 1); ("beta", 2); ("gamma", 3)]

The following code demonstrates using the List module functions map, filter, and fold_left. See the section “Pretty Printing” for details on [@@deriving show].

open Printf

type int_list = int list
[@@deriving show]

let numbers = [4; 1; 9; 7; 2]

let doubled = List.map (fun x -> x * 2) numbers

let even_numbers = List.filter (fun x -> x mod 2 = 0) numbers

let sum = List.fold_left (+) 0 numbers

let () =
  print_endline (show_int_list doubled); (* [8; 2; 18; 14; 4] *)
  print_endline (show_int_list even_numbers); (* [4; 2] *)
  printf "sum = %d\n" sum (* sum = 23 *)

The following code finds the maximum value in a list of numbers.

let rec list_max (lst : 'a list) : 'a option =
  match lst with
  | [] -> None
  | h :: t -> (
      match list_max t with None -> Some h | Some m -> Some (max h m))

let () =
  let numbers = [ 1; 13; 4; 9 ] in
  let max = list_max numbers in
  match max with
  | None -> print_endline "empty list"
  | Some max -> print_int max

Here is an easier way to find the maximum value in a list of numbers if we can assume the list is not empty.

let max_int x y = if x > y then x else y
let maximum =
  first = List.hd numbers in
  List.fold_left max_int first numbers

The fold_left and fold_right functions both take three arguments. But the order of the last two arguments differs. The first argument in both is a function that takes a value and an accumulator, but the order of those arguments differs. For example:

let numbers = [ 1; 2; 3 ]

let () =
  let sum = List.fold_left (fun acc n -> acc + n) 0 numbers in
  Printf.printf "fold_left result is %d\n" sum;

  let sum = List.fold_right (fun n acc -> acc + n) numbers 0 in
  Printf.printf "fold_right result is %d\n" sum

The following code sorts a list of strings:

["red"; "green"; "blue"] |> List.sort compare

The standard library doesn’t provide functions to take and drop a number of elements from a list, but the Base module does. See the take and drop functions described at List.

Association Lists

An association list is list of tuple pairs where the first value in each tuple is treated as a key and the second is treated as an associated value. Association lists are used in place of Map and Hashtbl collections when there are a small number of key/value pairs. This is because lookup in an association list can be slow where there are a large number of key/value pairs.

The List module provides the following functions for operating on association lists.

For example:

(* Create an association list. *)
let al1 = [ ("red", "FF0000"); ("green", "00FF00"); ("blue", "0000FF") ]

(* Create a new association list from al1
   where the "green" key/value pair is removed. *)
let al2 = List.remove_assoc "green" al1

(* Create a new association list from al1
   where the "yellow" key/value pair is added. *)
let al3 = ("yellow", "FFFF00") :: al2

let () =
  (* Get the value for the "red" key in al1. *)
  assert (List.assoc "red" al1 = "FF0000");
  (* Determine if the key "red" is present in al1. *)
  assert (List.mem_assoc "red" al1);
  (* Determine if the key "purple" is present in al1. *)
  assert (not (List.mem_assoc "purple" al1));
  (* Determine if the key "yellow" is present in al3. *)
  assert (List.mem_assoc "yellow" al3)

Arrays

An array is a mutable, ordered collection of values that all have the same type. Its length is fixed.

To create an array, surround the elements in square brackets that have vertical bars inside them and separate them with semicolons. For example:

let colors = [| "red"; "green"; "blue" |]

To get an element from an array, follow it with a dot and a zero-based index in parentheses (odd syntax) or use the Array.get function. For example:

let color = colors.(1) (* "green" *)
OR
let color = Array.get colors 1

To modify an array element, use the <- operator or the Array.set function. For example:

colors.(1) <- "yellow"
OR
Array.set colors 1 "yellow"

The type of an array is written as t array where t is the type of the elements. For example, the type of an array of float values is float array.

An empty array is written as [||] and has the type 'a array to indicate that the type of its elements is unknown.

The standard library Array module provides many functions that operate on arrays. See the Array module. Some highlights include the following:

Sets

A Set is an immutable, ordered collection of values that all have the same type with no duplicates. It it implemented with a balanced binary tree.

The following code demonstrates creating and using two set types, one for int values and one for dog record values.

open Printf

module IntSet = Set.Make (struct
  type t = int

  (* Int. below can be inferred. *)
  let compare = Int.compare
end)

type dog = { name : string; breed : string }

module DogSet = Set.Make (struct
  type t = dog

  (* String. below can be inferred. *)
  let compare a b = String.compare a.name b.name
end)

let () =
  let intSet = IntSet.of_list [ 3; 5; 3 ] in
  IntSet.iter (fun n -> print_endline (string_of_int n)) intSet;

  let dogSet =
    DogSet.(
      empty (* returns an empty Set *)
      |> add { name = "Comet"; breed = "Whippet" }
      |> add { name = "Oscar"; breed = "GSP" }
      |> add { name = "Comet"; breed = "Greyhound" })
  in
  DogSet.iter (fun dog -> printf "%s is a %s.\n" dog.name dog.breed) dogSet

Records

A record an immutable collections of named fields. The names of record types, like all type names, must begin with a lowercase letter. The fields can have different types, including other record types. Records are similar to structs in other languages.

The following code defines a record type that describes an item available for purchase.

type item = {
  description : string;
  mutable price : int;
  weight : float;
}

The field names must begin with a lowercase letter.

The field values are immutable by default, but can be made mutable by adding the mutable keywored before their field name.

To create a record, supply values for each of the fields inside curly braces in any order. For example:

let my_item : item = { description = "milk"; price = 350; weight = 1. }

It is not necessary to specify the type of the record variable. But the field names and values must match some existing record type and no extra fields can be present.

Field values can be omitted if there is a variable in scope with the same name as the field. This is called “field punning”. For example:

let description = "milk" and price = 350 and weight = 1. in
let my_item = { description; price; weight } in
...

To access a field value in a record, use dot syntax. For example:

let p = my_item.price

A field name must follow the dot, not an expression that evaluates to a field name. To lookup values based on an expression, use a Map instead of a record.

Fields can also be pattern matched. For example:

match my_item with
| {description=d; price=p; weight=w} ->
    (* can use d, p, and w here *)

Alternatively there is a shorthand for setting variables whose names match the field names.

match my_item with
| {description; price; weight} ->
    (* can use description, price, and weight here *)

To modify a mutable field in a record, use the <- operator. For example:

milk.price <- 400

To create a new record by copying fields from an existing one and using different values for some of its fields, use the with keyword. For example:

let new_milk = { milk with price = 325; weight = 1.5 }

The following code demonstrates creating and using a list of records.

open Printf

type item = {
  description : string;
  mutable price : int;
  weight : float;
}

let eggs = { description = "eggs"; weight = 0.4; price = 275 }
let milk : item = { description = "milk"; weight = 1.; price = 350 }
let new_milk = { milk with price = 325; weight = 1.5 }
let items = [ eggs; new_milk ]

let print_item item =
  printf "%s: $%d (%f lbs)\n" item.description item.price item.weight

let () =
  milk.price <- 400;
  List.iter print_item items;
  let total = List.fold_left (fun acc item -> acc + item.price) 0 items in
  printf "Total: $%d\n" total

Maps

A Map is an immutable collection of key/value pairs.

The standard library Map module provides many functions that operate on maps. Each of them return a new map that uses structual sharing to avoid making a copy of the whole map. See the Map module.

To create a map type that uses keys of a given type, call Map.Make. For example, the following creates a map type where the keys are strings.

module StringMap = Map.Make (String)

Module names, like StringMap above, must start with an uppercase letter.

To create an instance of this map type that starts empty, call the empty function on the map type. For example:

let dog_map = StringMap.empty

To create a new map from an existing one adding one key/value pair, call the add function on the map type passing it a key, a value, and an existing map. For example:

This code uses the Uuidm module to generate uuids that are used as keys in the map. It must be installed with opam install uuidm.

let generate_uuid () = Uuidm.(v `V4 |> to_string)
let uuid = generate_uuid () in
let new_dog_map = StringMap.add uuid dog dog_map

To create an instance of this map that that starts with some key/value pairs, use the of_seq function on the map type as shown in the code below.

let make_dog name breed =
  let uuid = generate_uuid () in
  { id = uuid; name; breed }
let comet = make_dog "Comet" "whippet"
let oscar = make_dog "Oscar" "GSP"
let dog_map = StringMap.of_seq @@ List.to_seq [
  (comet.id, comet);
  (oscar.id, oscar);
]

To find a value in a map by its key, use the find_first_opt function on the map type. This returns an Option because it’s possible the key will not be found. For example:

let dog_opt = StringMap.find_first_opt (fun key -> key = "some-key") dog_map

To change the value for a given key, use the update function on the map type.

let new_dog_map = dog_map |> StringMap.update "some-key" new_value

To create a new map from an existing one where one key/value pair is removed, use the remove function on the map type. For example:

let new_dog_map = dog_map |> StringMap.remove "some-key"

The following code demonstates all the operations described above.

module StringMap = Map.Make (String)

let () =
  let map =
    StringMap.empty |> StringMap.add "a" "apple" |> StringMap.add "b" "banana"
    |> StringMap.update "a" (Option.map (fun _ -> "apricot"))
    |> StringMap.remove "b"
  in
  let a_fruit = StringMap.find_opt "a" map in
  match a_fruit with
  | None -> print_endline "No such fruit"
  | Some fruit -> print_endline fruit

The following code demonstrates using a Map to store a collection of dog descriptions and prints information about each dog.

open Printf

let generate_uuid () = Uuidm.(v `V4 |> to_string)

module StringMap = Map.Make (String)

type dog = { id : string; name : string; breed : string }

let add_dog map name breed =
  let uuid = generate_uuid () in
  let dog = { id = uuid; name; breed } in
  StringMap.add uuid dog map

let print_dog _ dog = printf "%s) %s is a %s.\n" dog.id dog.name dog.breed

let () =
  let dog_map = StringMap.empty in
  let dog_map = add_dog dog_map "Comet" "whippet" in
  let dog_map = add_dog dog_map "Oscar" "GSP" in
  StringMap.iter print_dog dog_map

Hashtbl

A Hashtbl is similar to a Map, but it is mutable.

The Hashtbl module supports the following functions:

Like with any module, if you call open Hashtbl then these function can be called without the Hashtbl. prefix.

To create a Hashtbl instance, call the Hashtable.create function passing it an estimate for the number of key/value pairs that will added. It can expand to hold more, but providing a good estimate can make add entries more efficient.

let my_hash = Hashtbl.create 10

Initially the hashtable does not know the type of the keys and values. Once the first entry is added, those types will be fixed and all subsequent entries must use the same types for their keys and values.

The first argument to all the remaining functions is a Hashtbl instance, with the exception of the iter function where it is the last argument.

The add function can add multiple values for the same key, and can even add the same value multiple times. The previous values are not overwritten.

Hashtbl.add my_hash "whippet" "Rudy"
Hashtbl.add my_hash "whippet" "Dasher"
Hashtbl.add my_hash "whippet" "Comet"

To have only one value for each key, use the replace function instead. The replace function adds a new key or replaces an existing one.

Hashtbl.replace my_hash "whippet" "Comet"

The find function raises a Not_found exception if the key is not found.

let name = Hashtbl.find my_hash "whippet"

The find_all function returns an empty list if the key is not found.

let names = Hashtbl.find_all my_hash "whippet"

The remove function doesn’t complain if the key being removed doesn’t exist.

Hashtbl.remove my_hash "whippet"

The following code demonstrates creating a Hashtbl that holds a collection of dogs. The keys are dog ids and the values are dog records.

open Printf

type dog = { id : string; name : string; breed : string }

(* 10 is an estimate for the number of entries that will be added. *)
let dog_map = Hashtbl.create 10

let generate_uuid () = Uuidm.(v `V4 |> to_string)

let add_dog name breed =
  let id = generate_uuid () in
  Hashtbl.add dog_map id { id; name; breed }

let print_dog dog = printf "%s is a %s (id=%s).\n" dog.name dog.breed dog.id

let () =
  add_dog "Comet" "Whippet";
  add_dog "Oscar" "GSP";
  (* The function passed to `iter` takes a key and value from the Hashtbl. *)
  Hashtbl.iter (fun _ dog -> print_dog dog) dog_map

Functions

OCaml functions are first-class. They can take other functions as arguments and can return new functions.

Function definitions must appear before any calls to them.

OCaml functions cannot be overridden based on their number of parameters or parameter types.

The syntax a b c means calling function a with the arguments b and c.

Another way to write this is to use the “reverse function application” operator |> which is intended to look like a right pointing triangle. In fact, in fonts that support ligatures, it is displays as exactly that. Using this, the equivalent of a b c is c |> b |> a. This operator is typically used with functions that take a single argument. The following code demonstrates two ways to compute the squared value of the sine of an angle.

The body of a function definition, the part after the =, is a single expression. An expression can be a semicolon-separated set of expressions, but typically there is only one. When there are more than one, all but the final expression serve to cause side effects and must have the unit type (no value). Typically these serve to assign the results of intermediate computations to variables or perform debug printing. The result of a function call is the value of the final expression.

let square x = x *. x
let angle = 0.78 (* radians *)
let result1 = square (sin angle)
(* The following is equivalent expression that uses
   the reverse function application operator. *)
let result2 = angle |> sin |> square

The OCaml syntax for defining and calling functions is inspired by lambda calculus.

In order to call a function that takes no arguments, such as print_newline, it must be “passed” the “unit” value (). Without this it is just a reference to the function and not a call to it.

Functions that only produce side effects do not return anything. Calls to them are expressions with “unit type”, represented by (). These are like “statements” in other languages. Some call them “effectful expressions”.

There are two ways to return early from a function … using the exit (not typically used) or raise keywords (raises an exception).

Anonymous functions (aka lambdas) are defined using the fun function. For example the following function takes two int arguments and returns an int. Note how no parentheses are required and the parameters are just separated by spaces.

fun a b -> a + b

It is not necessary to specify these types. They are inferred from the function expression a + b based on the fact that the + operator only operates on int values and returns an int value.

The types can be specified if desired. The main reason to do so is to add documentation so readers of the code don’t have to examine the function body to determine the types. To specify the parameter types and the return type, the function above can be written as the following.

fun (a : int) (b : int) : int -> a + b

If this function definition is entered in a REPL, followed by ;;, the output will be - : int -> int -> int = <fun>. The dash at the beginning indicates that the value does not have a name. The first and second occurrences of int are the types of the two parameters. The last int is the return type of the function. The <fun> after the = represents the bytecode for the function which cannot be printed.

When a function is called with fewer arguments than it has parameters, a new function is returned that is the result of partial application. That is why one arrow (->) for each parameter appears in the output.

In fact, the function definition above is just syntactic sugar for the following which only defines single-parameter function.

fun a -> (fun b -> a + b))

Despite not having a name, this function can be invoked by surrounding it in parentheses. For example, the following evaluates to 5. Note how no parentheses are required around the arguments which are just separated by a space.

(fun a b -> a + b) 2 3

Let’s give a name to this function and invoke it in a couple of ways.

let add = (fun a b -> a + b) in
print_int (add 1 2); (* 3 *)

(* Shorthand for previous way of defining this function *)
let add a b = a + b in
print_int (add 1 2); (* 3 *)

(* Even shorter with point-free style! *)
let add = (+)

In the call to print_int above, parentheses are needed around add 1 2 so that is evaluated before the print_int function is called.

Let’s use partial application to create a new function that only takes a single number and adds 5 to it.

let add5 = (add 5) in
print_int (add5 2); (* 7 *)

In the expression e1 e2 e3, e1 must evaluate to a function and it is passed the values of e2 and e3. If e2 or e3 are not primitive values or variables, add parentheses around those expressions so they are evaluated before the function call to e1 is evaluated. For example, our add function above can be called as follows:

add (2 * 3) (4 + 5) (* 6 * 9 = 54 *)

Labeled parameters allow them to be specified by name in calls. A function can have a mixture of labeled and unlabeled parameters. Unlabeled parameters are positional and must be passed in the order they are specified. Labeled parameters can be specified in any order and can be mixed into the unlabeled parameters.

To declare a labelled parameter, use the syntax ~arg_name:param_name where arg_name is the name used in callsx and param_name is the name used in the function implementation. If arg_name is the same as param_name, this can be shortened to just ~arg_name.

To pass an labeled argument, use the syntax ~arg_name:value. For example, ~maximum:100.

open Printf

(* This doesn't use labeled parmeters. *)
let rectangle_area1 length width = length *. width

(* This does use labeled parmeters.
   The name between ~ and : is what will be used in calls.
   The name after the : is what will be used in the function body. *)
let rectangle_area2 ~length:l ~width:w = l *. w

let () =
  printf "area1 = %f\n" (rectangle_area1 8.5 11.);
  printf "area2 = %f\n" (rectangle_area2 ~length:8.5 ~width:11.)

Labeled parameters can specify default values which makes them optional. Use the syntax ?arg-name:(param-name = default_value). If arg_name is the same as param_name, this can be shortened to just ?(arg_name = default_value). Optional labeled parameters must appear before the non-optional parameters.

Functions that have any optional parameters must have at least one positional parameter. This is required because OCaml does not surround arguments with parentheses and so needs a way to know when the last argument has been reached. When no positional parameters are needed, specify () as the last one. In this case calls to the function must also end with ().

For example:

open Printf

(* When using optional parameters, there must be at least one
   that is not optional.  Adding `()` satisifies this. *)
let greet ?(name = "World") ?(suffix = "!") () =
  printf "Hello, %s%s\n" name suffix

let product ?(a = 1.) b = a *. b

let sum2 ?alpha:(first = 1) ?(beta = 2) () = first + beta

let sum3 ?alpha:(first = 1) ?(beta = 2) ~gamma () = first + beta + gamma

let () =
  (* In calls to functions with no required parameters, include `()`.
     It doesn't matter where it appears in the argument list. *)
  greet ~name:"Mark" ~suffix:"." (); (* Hello, Mark. *)
  greet () ~name:"Mark"; (* Hello, Mark! *)
  greet () (* Hello, World! *)

  printf "%f\n" (product ~a:8.5 2.); (* 17 *)
  printf "%f\n" (product 8.5); (* 8.5 *)

  printf "%d\n" (sum2 ~alpha:3 ~beta:4 ()); (* 7 *)
  printf "%d\n" (sum2 ~alpha:3 ()); (* 5 *)
  printf "%d\n" (sum2 ~beta:4 ()); (* 5 *)
  printf "%d\n" (sum3 ~gamma:5 ()) (* 8 *)

Recursive functions must be defined with let rec. For example:

let rec factorial n =
  if n < 0 then
    (* raises an exception *)
    failwith "factorial is not defined for negative numbers"
  else if n = 0 then 1
  else n * factorial (n - 1)

The failwith keyword is sometimes used in place of code that is not ready to be written. For example, failwith "TODO".

Function parameters can use pattern matching to extract elements from tuples. This can also be done for lists and arrays, but those require special handling due to non-exhastive matching. The reason is that by definition tuple types have a known size, but list and array types do not. Recall that:

• The type of the tuple (1, 2, 3) is int * int * int which has a length of 3.
• The type of the list [1; 2; 3] is int list which does not specify a length.
• The type of the array [|1; 2; 3|] is int array which does not specify a length.

The following code demonstrates ways to use pattern matching on tuples, lists, and arrays.

open Printf

(* This only handles tuples of length 4. *)
let tuple2of4 (_, e, _, _) = e
(* alternate implementation *)
(* let tuple2of4 tuple = match tuple with a, b, c, d -> b *)

(* This only handles lists of length 4. *)
let list2of4 = function
  | [ _; e; _; _ ] -> e
  | _ -> failwith "list must have length 4"

(* This only handles arrays of length 4. *)
let array2of4 = function
  | [| _; e; _; _ |] -> e
  | _ -> failwith "array must have length 4"

let () =
  let t = ("a", "b", "c", "d") in
  (* This pattern matches a tuple in a variable declaration. *)
  let _, second, third, _ = t in
  printf "second in tuple is %s\n" second;
  printf "third in tuple is %s\n" third;
  printf "second in tuple is %s\n" (tuple2of4 t);

  let l = [ "a"; "b"; "c"; "d" ] in
  printf "second in list is %s\n" (list2of4 l);

  let a = [| "a"; "b"; "c"; "d" |] in
  printf "second in array is %s\n" (array2of4 a)

A common OCaml idiom to hide the use of an accumulator parameter is to nest a function inside another. For example, see the visit function that is nested inside the reverse_int_list function here. This uses tail recursion so recursion does not cause the call stack to grow.

let reverse_int_list l =
  let rec visit acc l =
    match l with [] -> acc | hd :: tl -> visit (hd :: acc) tl
  in
  visit [] l

let rec print_int_list l =
  match l with
  | [] -> ()
  | hd :: tl ->
      print_int hd;
      print_char ' ';
      print_int_list tl

let () =
  let numbers = [ 1; 2; 3; 4; 5 ] in
  let rev = reverse_int_list numbers in
  print_int_list rev;
  print_newline ()

OCaml does not make it easy to write variadic functions, which are functions that take a variable number of arguments. One approach is to take a list, but that requires all the values to have the same type. Another approach is to use a generalized algebraic data type (GADT), but that introduces complexity.

Function Composition

OCaml does not define an operator for function composition, but you can define one. The following code demonstrates four ways to define a new function that composes existing functions.

let add1 x = x + 1
let square x = x * x
let add1square x = x |> add1 |> square
let add1square' x = square @@ add1 x
let ( << ) f g x = f (g x)
let add1square'' = square << add1
let ( >> ) f g x = g (f x)
let add1square''' = add1 >> square

let () =
  assert (add1square 2 = 9);
  assert (add1square' 2 = 9);
  assert (add1square'' 2 = 9);
  assert (add1square''' 2 = 9)

The Base module defines the Fn.compose function which composes a pair of functions from right to left. It can be used as follows:

open Base
let add1square = Fn.compose square add1

Modules

A module provides a namespace for a set of related values that can be types, exceptions, constants, and functions. Constants and functions are defined with let definitions. Module names always begin with an uppercase letter and they use CamelCase by convention.

Modules often describe a data type, ways to create instances, and operations on instances. Examples of such modules defined in the standard library include Array, Char, Hashtbl, List, Map, Option, Queue, Result, Set, Stack, and String. Standard library modules that do not describe a data type include Printf, Random, Sys, and Unix.

Modules that define a data type do not define methods that are called on instances. Instead they define functions to which an instance and other arguments are passed. For example, the List module defines the map function that is used as follows:

let numbers = [4; 1; 9; 7; 2]
let doubled = List.map (fun x -> x * 2) numbers

Every .ml source file defines a module. For example, the file demo.ml defines the module Demo. These can contain the following:

• open statements that make the names in another module available without a module name prefix
• include statements that include values defined in another module as if they were defined in the current file.
• type definitiions
• exception definitions
• let definitions that define constants and functions
• module definitions that define submodules

A package is a collection of related libraries and a library is a collection of related modules.

Modules provides a way to identify multiple values that happen to have the same name. For example, the List and Array modules both define the map function.

Modules also serve to hide complexity.

A submodule can be defined with the syntax module ModuleName = struct ... end.

The following code defines a module that contains functions for converting temperature values and demonstrates using it.

module Temperature = struct
  let c_of_f fahrenheit = (fahrenheit -. 32.) *. (5. /. 9.)
  let f_of_c celsius = (9. /. 5. *. celsius) +. 32.
end

let () =
  print_float (Temperature.c_of_f 100.);
  (* 37.8. *)
  print_newline ();
  print_float (Temperature.f_of_c 0.);
  (* 32.0 *)
  print_newline ()

Another way to define a module is to describe its interface in a .mli file and it’s implementation in a .ml file with the same name. This approach is describe in the “Signatures” section below.

Modules cannot be used like values. They cannot be assigned to a variable, passed to a function, or returned from a function.

Consider the following code which uses values from the Hashtbl module multiple times. There is no need to “import” the module as is done in many other programming languages.

let dog_table = Hashtbl.create 10
let () =
  Hashtbl.add dog_table "Comet" "Whippet";
  Hashtbl.add dog_table "Oscar" "GSP";
  Hashtbl.iter
    (fun name breed -> Printf.printf "%s is a %s.\n" name breed)
    dog_table

There are multiple ways to avoid repeating a module name every time the values it defines are referenced. The options include:

• global open

  Adding open Hashtbl at the top of a source file allows unprefixed names to be used anywhere in the source file. This works fine as long is the names don’t collide with names defined in other modules that also use a global open.

  open Hashtbl
  let dog_table = create 10
  let () =
    add dog_table "Comet" "Whippet";
    add dog_table "Oscar" "GSP";
    iter
      (fun name breed -> Printf.printf "%s is a %s.\n" name breed)
      dog_table


• local option

  For example, let open Hashtbl in narrows the scope in which unprefixed names can be used to the expression that follows.

  let dog_table = Hashtbl.create 10
  let () =
    let open Hashtbl in
    add dog_table "Comet" "Whippet";
    add dog_table "Oscar" "GSP";
    iter
      (fun name breed -> Printf.printf "%s is a %s.\n" name breed)
      dog_table


• dot and parentheses

  For example, Hashtbl.(...) narrows the scope in which unprefixed names can be used to the expression inside the parentheses.

  let dog_table = Hashtbl.create 10
  let () =
    Hashtbl.(
      add dog_table "Comet" "Whippet";
      add dog_table "Oscar" "GSP";
      iter
        (fun name breed -> Printf.printf "%s is a %s.\n" name breed)
        dog_table
    )


Modules can be nested to create a hierachy of namespaces, but it seems this is rarely used.

Circular dependencies between modules are not allowed.

Stdlib Module

There is an implicit open for the module Stdlib, so all of its members can be accessed without the module name prefix.

Commonly used members include:

• many operators
• many math functions
• many type conversion functions
• input/output functions
• ref and operators on them
• result variant type
• exit and at_exit
• a large number of standard library modules
• tuple functions for pairs, fst and snd
• ceil and floor
• failwith, invalid_arg, and raise
• many exceptions
• compare
• max and min
• nan
• not
• debugging dunderbars (ex. __FILE__, __FUNCTION__, and __LINE__)

The following code demonstrates using the debugging dunderbar values.

let log file fn line =
  Printf.printf "file: %s; function: %s; line: %d\n" file fn line

let demo () =
  print_endline "entered demo";
  log __FILE__ __FUNCTION__ __LINE__;
  print_endline "exiting demo"

let () = demo ()

Printf Module

The Printf module defines many functions that produce string output using a format string.

Perhaps the most commonly used function of these is printf. It takes a format string and a number of additional arguments equal to the number of placeholders in the format string. Commonly used placeholders include

• %s for string values
• %d for int values
• %f for float values including trailing zero decimal places
• %F for float values excluding training zero decimal places
• %.2f for float values with two decimal places
• %B for bool values (outputs “true” or “false”)

Ending the format string with %! causes it to flush the output buffer.

Signatures

The concept of “interfaces” in other programming languages is supported in OCaml with “signatures”. These can be used to specify that multiple modules support the same set of functions.

A signature is defined with the syntax module type ModuleTypeName = sig ... end. It can contain the following kinds of specifications: type, exception, val, and module type.

The following code demonstrates defining a signature and two modules that conform to it.

open Printf

module type Shape = sig
  type t

  val area : t -> float
end

(* float represents radius *)
module Circle : Shape with type t := float = struct
  let area radius = Float.pi *. radius *. radius
  (* Any extra values, including functions, define here
     that are not described in the `Shape` signature
     will be private to this module (not exposed outside).
     We say the module is "sealed". *)
end

(* float * float represents length and width *)
module Rectangle : Shape with type t := float * float = struct
  let area (length, width) = length *. width
end

let () =
  let radius = 5. in
  let circle_area = Circle.area radius in
  printf "Circle area: %.2f\n" circle_area;

  let length = 4. and width = 6. in
  let rectangle_area = Rectangle.area (length, width) in
  printf "Rectangle area: %.2f\n" rectangle_area

Files with the .mli extension contain signatures of functions defined in the corresponding .ml file. This pair of files is called a “compilation unit”. Code that uses this unit can only access what the .mli file describes.

For example, see the definitions of the standard library modules in the GitHub repository for OCaml at ocaml/stdlib. The file list.mli defines the signatures for the List module and the file list.ml defines the implementations.

The is_empty function has the signature

val is_empty : 'a list -> bool

and the implementation

let is_empty = function
  | [] -> true
  | _ :: _ -> false

As another example, here is the file math.mli:

type point = float * float

(**
Computes the distance from one point to another.
@param p1 the first point
@param p2 the second point
@return the distance between them
*)
val distance : point -> point -> float

And here is the file math.ml:

(* This defines the "Math" module which is in the "Module_demo2" library. *)
type point = float * float

(* private function *)
let square x = x *. x

(* public function *)
let distance (x1, y1) (x2, y2) =
  let dx = x2 -. x1 in
  let dy = y2 -. y1 in
  sqrt ((square dx) +. (square dy))

Note how the point type is define in both the .mli and .ml files. This is typical. A way to avoid this duplication is described in The _intf trick.

Here is the file main.ml that uses the Math module defined above:

let () =
  let p1 = (0., 0.) in
  let p2 = (3., 4.) in
  let d = MyLibrary.Math.distance p1 p2 in
  assert (d = 5.)

The Language Server Processor (LSP) will display the help text for the distance function when hovering over the call to the function above in an editor that is configured to use the LSP such as VS Code.

Files with the .cmi extension are compiled versions of .mli files and files with the .cmo extension are compiled versions of .ml files.

TODO: Can an OCaml class implement a signature?

Functors

TODO: Describe these. See Functors.

Exception Handling

The built-in type exn is an extensible variant type that has constructors for all the built-in exceptions. Examples include Division_by_zero, Failure, Invalid_argument, and Not_found. For a full list, see Index of exceptions.

The exception keyword creates a custom exception that is added as a constructor of the exn type. Exceptions can optionally have an associated value of any type. For example:

exception BadThingHappened
exception TemperatureTooHigh of float

The raise keyword raises a given exception. For example:

raise BadThingHappened
raise (TemperatureTooHigh 99.9)

There are predefined functions that simplify raising common exceptions.
failwith "data not found" is short for raise (Failure "data not found").
invalid_arg "bad 1st arg" is short for raise (Invalid_argument "bad 1st arg").

The try keyword enables catching exceptions raised by an expression. It is similar to the match keyword, but the branches must match on exceptions. The value of each branch must have the same type. If no branch matches a raised exception, the exception is re-raised. For example:

open Printf

exception TemperatureCrazy
exception TemperatureHigh of float

let evaluate_temperature temp =
  if temp >= 120. then raise TemperatureCrazy;
  if temp >= 100. then raise (TemperatureHigh temp);
  if temp < 32. then "cold" else if temp < 75. then "hot" else "nice"

let report_temperature t =
  try printf "%.1f is %s\n" t (evaluate_temperature t) with
  | TemperatureCrazy -> printf "%.1f is a crazy temperature!\n" t
  | TemperatureHigh t -> printf "%.1f is too hot!\n" t

(* Alternative that does the same thing and
   is good for matching both exceptions and other values.
   let report_temperature t =
     match evaluate_temperature t with
     | exception TemperatureCrazy -> printf "%.1f is a crazy temperature!\n" t
     | exception TemperatureHigh t -> printf "%.1f is too hot!\n" t
     | s -> printf "%.1f is %s\n" t s
*)

let () =
  report_temperature 80.;
  (* "80.0 is nice" *)
  report_temperature 50.;
  (* "50.0 is nice" *)
  report_temperature 20.;
  (* "20.0 is cold" *)
  report_temperature 100.;
  (* "100.0 is too hot!" *)
  report_temperature 120. (* "120.0 is a crazy temperature!" *)

The built-in function assert takes a Boolean expression and raises an Assert_failure if if evaluates to false. This is good for verify conditions that must hold in order for the program to run correctly.

Source Files

The code in a source file is executed just as it would be in a REPL if it were terminated by a double semicolon.

Every source file defines a module. The identifiers it defines, including types, constants, and functions, can be used in other source files. The name of a module is inferred from its source file name by uppercasing its first letter. For example, the file foo_bar.ml defines the module Foo_bar.

Suppose this file defines the function baz. To call this function in another source file, use Foo_bar.baz. Alternatively, include an open statement to allow all the identifiers in a given module to be used in the current source file without prefixing them with their module name. If we have open Foo_bar then the baz function can be used without the Foo_bar. prefix.

OCaml source files contain the following kinds of statements:

• open statements
• constants defined with let definitions
• functions defined with let definitions
• an optional “main” expression that begins with let () =

Here’s an example of a file named math.ml that defines a type, a constant, and some functions that can be used by other source files.

type point2d = float * float

let pi = Float.pi

let add a b = a + b

let average numbers =
  let sum = List.fold_left (+) 0 numbers in
  let length = List.length numbers in
  float_of_int sum /. float_of_int length

(* This demonstrates adding types to parameters and
   specifying the return type, all of which can be inferred. *)
let distance ((x1, y1) : point2d) ((x2, y2) : point2d) : float =
  let dx = x2 -. x1 in
  let dy = y2 -. y1 in
  sqrt ((dx *. dx) +. (dy *. dy))

Here is a “main” source file, typically named main.ml, that uses things defined in math.ml. It defines a constant, a function, and a expression that is executed when this file is passed to the ocaml command.

open Math
open Printf

let my_constant = 7

let square x = x * x (* a function *)

(* Note the use of semicolons to separate
   the statements and expressions. *)
let () =
  (* This is a verbose way to print a value. *)
  print_string "my_constant = ";
  print_int my_constant;
  print_newline ();

  (* This is a more concise way to print a value. *)
  printf "pi = %f\n" pi; (* defined in math.ml *)

  (* This calls a function defined in this file. *)
  printf "square of %d = %d\n" my_constant (square my_constant);

  (* The remaining examples call functions defined in math.ml. *)
  let a = 1 and b = 2 and c = 3 in
  printf "sum of a and b = %d\n" (add a b);

  let numbers = [a; b; c] in
  let avg = average numbers in
  printf "average of a, b, and c = %f\n" avg;

  let p1 = (0., 0.) and p2 = (1., 1.) in
  let d = distance p1 p2 in print_float d

When these files appear in the bin directory of a Dune project, the program can be run by entering dune exec {project-name}.

To run this outside of a Dune project, create an executable by entering ocamlopt math.ml main.ml -o demo and run it by entering ./demo.

The module keyword can be used to define a submodule. For example, the file math.ml defines the module Geometry. If it contains module Geometry = struct ... end then the things it defines are in the module Math.Geometry.

For example, suppose in a Dune project the file lib/math.ml contains the following:

let average numbers =
  let sum = List.fold_left (+.) 0. numbers in
  let length = List.length numbers in
  sum /. float_of_int length

module Geometry = struct
  let rectangle_area width height = width *. height
  let rectangle_perimeter width height = width *. 2. +. height *. 2.
end

In the file bin/main.ml this can be used as follows:

open Demo.Math
(* Can also add this: open Demo.Math.Geometry *)
open Printf

let () =
  let avg = average [5.2; 3.5] in
  printf "average = %f\n" avg;
  let area = Geometry.rectangle_area 5.2 3.5 in
  printf "area = %f\n" area

Input/Output

The OCaml standard library provides many functions that read input.

The following functions read from stdin:

• read_line - raises End_of_file if there is no more to read
• read_int_opt - returns None if conversion fails
• read_int - raises Failure "int_of_string" if conversion fails
• read_float_opt - returns None if conversion fails
• read_float - raises Failure "float_of_string" if conversion fails

The OCaml standard library provides many functions that produce output.

The following functions write to stdout:

• print_bytes
• print_char
• print_endline - prints a string followed by a newline
• print_float
• print_int
• print_newline - prints only a newline
• print_string

The following functions write to stderr:

• prerr_bytes
• prerr_char
• prerr_endline - prints a string followed by a newline
• prerr_float
• prerr_int
• prerr_newline - prints only a newline
• prerr_string

The following program prompts for two numbers and outputs their product.

(* Make the printf function available. *)
open Printf;;

print_string "Enter the first number: ";
let num1 = read_float () in

print_string "Enter the second number: ";
let num2 = read_float () in

let product = num1 *. num2 in
printf "The product of %.2f and %.2f is %.2f\n" num1 num2 product;

The following program reads and prints all the lines in a text file using a while loop.

let channel = open_in "BeverlyHillbillies.txt" in
try
  while true do
    (* input_line reads from a given channel
       until a newline or the end is reached. *)
    let line = input_line channel in
    print_endline line
  done
with End_of_file -> close_in channel

The following program reads and prints all the lines in a text file using recursion.

let channel = open_in "BeverlyHillbillies.txt" in
let rec loop () =
  try
    let line = input_line channel in
    print_endline line;
    loop ()
  with End_of_file -> close_in channel
in
loop ()

The following program creates a text file and writes lines to it.

let channel = open_out "output.txt" in
try
  (* output_string writes to a given channel. *)
  output_string channel "line 1\n";
  output_string channel "line 2\n";
  output_string channel "line 3\n";
  close_out channel
with ex -> close_out channel

Object-oriented Features

Objects and classes offer an alternative to records. Objects and records have fields, but objects can also have methods.

Most OCaml code uses modules instead of objects and classes.

The following code demonstrates defining and using a class (point). Classes, like types, have lowercase names by convention.

A class definition serves as its single constructor. A class cannot define additional constructors, but functions can be written to create instances in additional ways.

The point class and the origin function are wrapped in a module to make it clear that they are related. Modules have names that start uppercase by convention.

open Printf

module Geometry = struct

  (* Arguments passed to a constructor do not require a matching field
     and can be used in methods. *)
  class point (x_init : float) (y_init : float) =
    (* Can omit "(self)" if there are no references to it. *)
    object (self)
      (* Instance variables are immutable by default,
         but can be made mutable. *)
      val mutable x = x_init
      val mutable y = y_init

      (* Getter methods can have the same name as the field they return,
         but often they start with "get_". *)
      method get_x = x
      method get_y = y
      method set_x new_x = x <- new_x
      method set_y new_y = y <- new_y

      (* This is a named constructor. *)
      method origin = new point 0. 0.
      method print = printf "(%f, %f)\n" x y

      method translate dx dy =
        x <- x +. dx;
        y <- y +. dy
    end

  (* This is the OCaml version of a named constructor. *)
  let origin = new point 0. 0.
end

let () =
  (* Use the new keyword to create an instance of the class. *)
  (* let p = new point 0. 0. in *)
  (* This uses a named constructor function instead. *)
  let p = Geometry.origin in

  (* Methods are called with # instead of dot. *)
  p#set_x 1.;
  p#set_y 2.;
  p#translate 3. 4.;

  (* There is no need to pass the unit value `()`
     to call methods that have no parameters. *)
  printf "(%f, %f)\n" p#get_x p#get_y;
  p#print;

  (* The Oo.copy function makes a shallow copy of an object. *)
  let p2 = Oo.copy p in
  p2#set_x 5.;
  p2#print;

  (* Each object is assigned a unique id
     that can be accessed with Oo.id function. *)
  printf "p id = %d\n" (Oo.id p);
  printf "p2 id = %d\n" (Oo.id p2)

Abstract classes are defined with “class virtual”. Methods can be defined with “method virtual” to require subclasses to implement them.

To inherit from another class, add “inherit {class_name} {args}” inside “object (self)” to call its constructor.

To enable calling superclass methods, add “inherit {class_name} {args} as super” and then use “super#{method_name}” to call them.

To coerce a subclass value to a superclass type, use obj :> {superclass}.

The following code demonstrates defining an abstract class (shape) and classes that inherit from it (circle and rectangle). It also uses the point class defined above.

open Printf

module Geometry = struct
  class point (x_init : float) (y_init : float) =
    object (self)
      val mutable x = x_init
      val mutable y = y_init
      method get_x = x
      method get_y = y
      method set_x new_x = x <- new_x
      method set_y new_y = y <- new_y
      method print = printf "(%f, %f)\n" x y

      method translate dx dy =
        x <- x +. dx;
        y <- y +. dy
    end

  let origin = new point 0. 0.

  class virtual shape (name_init : string) =
    object
      val name = name_init
      method name = name
      method virtual area : float
    end

  class circle (center_init : point) (radius_init : float) =
    object
      inherit shape "circle"
      val center = center_init
      val radius = radius_init
      method area = 3.14159 *. radius *. radius
    end

  class rectangle (lower_left_init : point) (width_init : float)
    (height_init : float) =
    object
      inherit shape "rectangle"
      val lower_left = lower_left_init
      val width = width_init
      val height = height_init
      method area = width *. height
    end
end

let () =
  let p = Geometry.origin in
  let c = new Geometry.circle p 5. in
  printf "%s area = %f\n" c#name c#area;
  let r = new Geometry.rectangle p 10. 5. in
  printf "%s area = %f\n" r#name r#area

Dune

Dune is a popular OCaml and Reason build system. It is used create, build, test, and run OCaml projects. It can also compile to JavaScript.

To install the dune command, enter opam install dune.

For help, enter dune --help.

Creating

To create a project that uses dune, cd to where the project should be created and enter the following.

dune init project {project_name}

The project name can contain underscores, but not hyphens.

This generates many files including:

• dune configuration file dune-project
• opam configuration file {project_name}.opam
• _build, bin, lib, and test directories
• main source file bin/main.ml
• unit test file test/test_{project_name}.ml.

The bin directory holds source files that will be compiled to executables. These often use modules defines in the lib directory. It’s a bit odd that it hold source files rather than executables created by a build process.

It is common to have a file in the bin directory named main.ml, but that name is not required. It is also common to end files in the bin directory with an expression that begins with let () =. This is similar to the main function in other languages.

The lib directory is the preferred location for source files that define reusable functions. One reason is that Dune supports implementing unit tests for files in the lib directory, but not for files in the bin directory.

The test directory holds test files for tests that are not included inline with the functions they test. Inline tests are typically preferred.

When using git for version control, the _build directory should be added in the .gitignore file.

The bin, lib, and test directories all contain a dune file that holds configurations options for that directory. These files use s-expressions (also used in Lisp) that is an alternative to other data formats such as JSON. Each option is specified in by a name and value inside parentheses that is referred to as a “stanza”.

The lib directory can have subdirectories that contain .ml files and those can define additional types, constants, and functions. To make those accessible, add the following at the bottom of the lib/dune file:

(include_subdirs qualified)

For example, if the project name is “demo” and lib/sub/mod.ml defines the function greet then bin/main.ml can refer to it with Demo.Sub.Mod.greet.

An alternative to adding subdirectories in the lib directory is to create additional top-level directories that each define a different library.

For example:

• Create the top-level directory lib2.
• Create the file lib2/dune containing (library (name demo2))
• Create the file lib2/mod.ml containing let greet () = print_endline "Hello from lib2!"
• Update the libraries stanza in the bin/dune file to (libraries demo demo2)
• Add the call Demo2.Mod.greet () in bin/main.ml

Manually Creating

A Dune project can be created by manually creating a directory containing the three files dune-project, dune, and {project-name}.ml.

Suppose the project name is “my_dune_project”. Here is a minimal dune-project file. The first line specifies the version of the syntax used in this file and in the dune files, not the version of Dune being used.

(lang dune 3.14)
(package
  (name my_dune_project)
  (depends ocaml dune))

Here is a minimal dune file.

(executable
  (public_name my_dune_project))

Here is a minimal OCaml source file with the same name as the project, my_dune_project.ml.

let () = print_endline "Hello, World!"

To run this project, enter dune exec my_dune_project This may take 5 to 10 seconds the first time it is run. It will be much faster for subsequent runs.

If you prefer to name the main source file main.ml, add the (name main) stanza in the dune file.

Building

To build the project, enter dune build or just dune b. This creates _build/default/bin/main.exe. To automatically rebuild the project when code changes are detected, add the --watch flag.

Running

To run the project, enter dune exec {executable_name}. The executable name is specified in the public_name stanza found in the bin/dune file and defaults to the project name.

Cleaning

To clean a project, enter dune clean. This deletes the _build directory that contains generated files.

utop

To run utop with project libraries automatically available, enter dune utop. For example, in a project with a library named “demo”, a module named “math_lib”, and a function in that module named “add”, the following works: Demo.Math_lib.add 1 2.

Example Project

Let’s walk through creating a small OCaml project with Dune.

1. cd to the directory where the project should be created.

2. Enter dune init project demo

3. cd demo

4. Enter dune exec demo.

5. Verify that the output is “Hello, World!”.

6. Create the file lib/math.ml containing the following:

   let pi = Float.pi

   let add a b = a +. b

   let average numbers =
     let sum = List.fold_left (+.) 0. numbers in
     let length = List.length numbers in
     sum /. float_of_int length


7. Create the file lib/points.ml containing the following:

   type point2d = float * float

   (* This demonstrates adding types to parameters and
      specifying the return type, all of which can be inferred. *)
   let distance ((x1, y1) : point2d) ((x2, y2) : point2d) : float =
     let dx = x2 -. x1 in
     let dy = y2 -. y1 in
     sqrt ((dx *. dx) +. (dy *. dy))

   let%test _ = distance (1., 1.) (4., 5.) = 5.


8. Modify the file bin/main.ml to contain the following:

   (* Note how open requires the library name AND the module name. *)
   open Demo.Math
   open Demo.Points
   open Printf

   let my_constant = 7

   let square x = x * x (* a function *)

   (* Note the use of semicolons to separate the
      statements and expressions. *)
   let () =
     (* This is a verbose way to print a value. *)
     print_string "my_constant = ";
     print_int my_constant;
     print_newline ();

     (* This is a more concise way to print a value. *)
     printf "pi = %f\n" pi; (* defined in math.ml *)

     (* This calls a function defined in this file. *)
     printf "square of %d = %d\n" my_constant (square my_constant);

     (* The remaining examples call functions defined in math.ml. *)
     let a = 2. and b = 3. and c = 2.5 in
     printf "sum of a and b = %f\n" (add a b);

     let numbers = [a; b; c] in
     let avg = average numbers in
     printf "average of a, b, and c = %f\n" avg;

     let p1 = (0., 0.) and p2 = (1., 1.) in
     let d = distance p1 p2 in print_float d


   The let () = is required because at the module level, everthing needs to be in a binding. You could use let _ = instead which allows the expression to have any kind of value. But using let () = is preferred because it states that the expression does not return a value.

9. Enter dune exec demo.

10. Verify that the output is

    my_constant = 7
    pi = 3.141593
    square of 7 = 49
    sum of a and b = 5.000000
    average of a, b, and c = 2.500000
    1.41421356237


Signatures can be used to make some definitions in a module “private”. For example:

1. Create the file lib/geometry.ml to define the implementation of the Geometry module.

   type point = float * float

   module type Signatures = sig
     val distance : point -> point -> float
   end

   module Mod : Signatures = struct
     let square x = x *. x
     let distance (x1, y1) (x2, y2) = sqrt (square (x1 -. x2) +. square (y1 -. y2))
   end


2. Create the file lib/geometry.mli to define the public interface of the Geometry module.

   type point = float * float
   val distance : point -> point -> float


   This does not expose the square function.

3. Call the distance function in bin/main.ml.

   printf "distance = %f\n" (Demo.Geometry.distance (0., 0.) (1., 1.));


   This assumes the public_name of the executable is “demo”,

Unit Tests

Dune supports several kinds of tests, including inline, expectation, and “cram” tests. Expection tests are similar to Jest snapshot tests. Cram tests describe the output of a shell session. Jest is a JavaScript test framework.

The following steps add tests to the demo project above and run them. It seems that tests can only be used in libraries defined in the lib directory, not in the bin directory.

1. Enter opam install ppx_inline_test to enable only inline tests or enter opam install ppx_expect to enable both inline and expectation tests.

   PPX is short for “PreProcessor eXtension”.

2. Change lib/dune to the following:

   (library
     (name demo)
     (inline_tests)
     ; This only enables inline tests, not expectation tests.
     ; (preprocess (pps ppx_inline_test)))
     ; This enables both inline tests and expectation tests.
     (preprocess (pps ppx_expect)))


   Single line comments in dune files begin with ;.

3. Add the following lines in lib/math.ml:

   (* This is an inline test for the add function. *)
   let%test _ = add 1.2 2.3 = 3.5

   (* This is an expectation test for the average function. *)
   let%expect_test _ =
     print_float (average [2.; 3.; 2.5]);
     [%expect "2.5"]


4. Add the following lines in lib/points.ml:

   let%test _ = distance (1., 1.) (4., 5.) = 5.


5. Enter dune test or dune test -w to run in watch mode.

   You’ll see dune runtest in documentation, but dune test is shorter and is an alias.

6. Verify that there are no failed tests.

   When all the tests pass, there is no output. If any expecation tests fail, but the actual values are correct, enter dune promote to update all the expected values.

Tests can also be placed in the test directory. The following steps implement the same tests above in this way.

1. Replace the contents of the test/dune file with the following:

   (tests
     (libraries demo)
     (names add average)
   )


   If there is only one test, (tests can be changed to (test and (names can be changed to (name.

2. Create the file test/add.ml containing the following:

   open Demo

   let () = assert ((Math.add 1.2 2.3) = 3.5)


3. Create the file test/average.ml containing the following:

   open Demo

   let () = print_float (Math.average [2.; 3.; 2.5]); (* 2.5 *)


4. Create the file test/average.expected containing 2.5.

5. Enter dune test and verify that all the tests pass.

Also see the example project at odoc_demo which implements unit tests for the my_math module that it defines.

Multiple Executables

A Dune project can host the code for multiple executables. This is ideal for a collection of sample programs that demonstrate various features of OCaml.

To create a project like this:

1. cd to the directory where the project will be created.

2. Enter dune init project samples where “samples” is the project name.

3. cd samples

4. Delete all the directories and files that will not be needed. These includes the directories bin, lib, and test and the file samples.opam.

5. Edit the dune-project file to only contain the following:

   (lang dune 3.14)
   (package
     (name samples)
     (depends ocaml dune))


6. Create the file dune in the root directory of the project containing the following:

   (executables
     (names program1 program2)
     (libraries lib1 lib2))


   Replace program1 and program2 with the names of your sample .ml files. Replace lib1 and lib2 with the names of any libraries you install using opam that are used by your sample programs.

7. To run one of your sample programs such as foo.ml, enter dune exec ./foo.exe

opam Libraries

opam is a package manager for OCaml, similar to npm for JavaScript.

1. dune init project date_formatting

2. cd date_formatting

3. opam install odate

4. Edit bin/dune and change the libraries stanza to (libraries date_formatting odate).

5. Edit bin/main.ml and replace its contents with the following:

   module Date = ODate.Unix

   (* For documentation for date/time format strings, see
      https://github.com/MLstate/opalang/blob/master/lib/stdlib/core/date/duration.opa#L472
      A is day of week, B is month, d is day of month, Y is year.
      a and b give abbreviations.
   *)
   let date_format = "%A, %B %d %Y"

   let date_printer =
     match Date.To.generate_printer date_format with
     | Some p -> p
     | None -> failwith "could not generate printer"

   let () =
     let now = Date.now() in
     let s = Date.To.string date_printer now in
     print_endline s


6. dune exec date_formatting

Switches

To use specific versions of packages in projects, create and activate switches. A switch is a collection of packages that are tied to an OCaml version and can specify versions of packages.

There are two kinds of switches, global switches that can be used by multiple projects and local switches that are tied to a specific project directory.

To create a global switch, enter opam switch create {switch-name} {ocaml-version}. For example, opam switch my_project 5.1.1 The OCaml version cannot be omitted. Creating a new switch takes around four minutes to complete.

To change the current global switch, enter opam switch {switch-name} and eval $(opam env) to activate it.

To see the name of the currently activated global switch, enter opam switch.

To install packages in the currently activated global switch, enter opam install {package-name}.{version}

To return to the default global switch, use the same commands to change to any switch, but specify the name “default”.

To list all the currently defined global switches, enter opam switch list

To delete a global switch, enter opam switch remove {switch-name}

To create a local switch, cd to a project directory and enter opam switch create .. Local switches are automatically selected and activated when you cd to a project directory that has one. Switches consume a lot of disk space, so creating a local switch for each project is not recommended.

An alternative to a local switch is to link a global switch to a project directory. To do this, cd to the project directory and enter opam switch link {switch-name}

Pretty Printing

See the library ppx_deriving. This supports a number plugins for deriving functions from types, including enum, eq, fold, iter, make, map, ord, protobuf show, and yojson.

PPX is short for “PreProcessor eXtension”. These can add support for new syntax and generate/transform code.

To use this in a Dune project:

1. Install it by entering opam install ppx_deriving.

2. If using the yojson plugin, also enter opam install ppx_deriving_yojson.

3. Add the following stanza to the project dune file. Here we only use the show plugin which generates functions whose names begin with show_ that return pretty-printed strings.

   (preprocess (pps ppx_deriving.show ppx_deriving.yojson))


4. Annotate types to be pretty-printed. For example:

   type int_list = int list [@@deriving show]


5. Print instances of that type with the following:

   print_endline (show_int_list numbers);


   This outputs something like [1; 2; 3].

We can write a function to print the elements in a list as an alternative to using a ppx.

let print_int_list l =
  List.iter (Printf.printf "%d ") l;
  print_newline ()

let () =
  let numbers = [ 1; 2; 3 ] in
  print_int_list numbers

This outputs like 1 2 3.

Generating Documentation

The odoc tool generates HTML-based documentation from (** ... *) commands in .ml source files. Those commands can contain directives like @param and @result.

This must be installed by entering opam install odoc.

Dune only generates documentation for public libraries.

See the example project at odoc_demo.

To generate HTML documentation, enter dune build @doc. The generated index.html file will be in the _build/default/_doc/_html directory.

For more detail, see odoc for authors

HTTP Servers

There are several OCaml libraries for implementing HTTP servers that provide API endpoints. Popular options include:

• Dream - 1.5K GitHub stars
• Opium - 747 GitHub stars
• CoHTTP - 676 GitHub stars
• Ocsigen - not in GitHub

Dream

The steps to use the Dream web framework are:

• Install Dream by entering opam install dream

• cd to the directory where a new Dune project will be created.

• Enter dune init project dream_demo

• cd dream_demo

• Edit bin/dune and modify the libraries stanza to include dream.

• Edit bin/dune and add the following at the end to enable use of HTML templates:

  (rule
    (targets main.ml)
    (deps main.eml)
    (action (run dream_eml %{deps} --workspace %{workspace_root})))


• Delete bin/main.ml.

• Create bin/main.eml with the following:

  let hello who =
    <html>
      <body>
        <h1>Hello, <%s who %>!</h1>
      </body>
    </html>

  let () =
    Dream.run
    @@ Dream.logger
    @@ Dream.router [
      Dream.get "/" (fun _ -> Dream.html (hello "World"));
    ]


• Enter dune exec dream_demo --watch

• Browse localhost:8080

VS Code isn’t able to provide LSP support for files with a .eml extension. Using an extension of .eml.ml or .eml.html enables LSP support. But both extensions cause issues because the files contain a combination of OCaml code and HTML. Treating them as one or the other will cause VS Code to flag errors that are not actually errors.

For a more advanced Dream app that places the HTML templates in separate source files, see dream_demo.

Dream Templates are not well-supported in editors like VS Code. Many errors flagged in them are not real errors. If the templates are moved to separate files with the .eml.html file extension as recommended, hovering over OCaml values will not display their types.

For an alternative to Dream templates which doesn’t having tooling support issues, see dream-html.

Jane Street Modules

Jane Street created the modules Base, Core_kernel, and Core. The Base module is a minimal replacement for the OCaml standard library. The Core_kernal module extends Base and adds features. The Core module extends Core_kernel and adds UNIX APIs.

To use the Base module, install it with opam install base. In source files that use it, add open Base. This causes all values from the standard library to be marked as deprecated.

To use the Base module:

1. opam install base
2. Add base as a dependency in dune files.
3. Add open Base in source files.

The use of Jane Street modules somewhat splits the community in two.

Converting OCaml to JavaScript

Here are the steps to compile an OCaml program to JavaScript using Dune.

1. Install the “js_of_ocaml” compiler.

   Enter opam install js_of_ocaml-compiler.

2. Modify the dune file.

   It should contain the following where the main OCaml source file is hello.ml:

   (executables
     (names hello)
     (modes js))


3. Compile to JavaScript.

   Enter dune build ./hello.bc.js

   This generates a ridiculous amount of JavaScript code … over 9000 lines for a Hello World program. So this is not a serious option!

4. Run the code.

   Enter node _build/default/hello.bc.js

Preprocessor Extensions (ppx)

Preprocessor extensions are programs that are called at compile time to alter or add source code. They operate on the abstract syntax tree (AST) of the program.

For example, the syntax [%get_env "USER"] can be replaces by the value of the USER environment variable.

See Preprocessors and PPXs

Serializing Data

OCaml provides good support for serializing data to s-expressions, JSON, and binary (sequences of bytes).

For s-expressions, see the Sexplib.Sexp module.

For JSON, see the yojson library.

For binary, see the Marshal module.

TODO: Add detail on this.

Suppressing Errors

Sometimes it is desirable to suppress certain errors. For example, you have have a record type that contains a field that is not yet being used, but will be used in the future.

There are a couple of ways to do this. One way is to add [@warning "-unused-field"] immediately after the type keyword that defines the record type. Another way when using Dune is to add the stanza (flags (:standard -w -69)) to the dune file where 69 is the code for “unused-field” errors.

To see all the supported error codes, enter ocaml -warn-help.

Concurrency

There are multiple OCaml libraries that support concurrency. The one that seems most popular is eio.

To install eio, enter opam install eio_main.

Debugging

To use ocamldebug:

1. Add the following stanzas in the dune file of the executable:

   (flags (:standard -g))
   (modes byte)


2. Build the executable with dune build. This creates a .bc bytecode file in the _build/default directory.

3. Enter ocamldbug _build/default/{name}.bd

4. Enter ocamldebug commands like step, next, print, break, continue, and quit.

I wasn’t able to set a breakpoint or print any expressions.
